330 ton AIDA 84.65” x 39.37” Stamping Press
No longer available
330 ton AIDA 84.65” x 39.37” Stamping Press
Specifications
| Manufacturer | AIDA |
| Model | PMX-L2-300-3000 |
| Year | 1996 |
| Condition | Used |
| Stock Number | 11410 |
| Capacity | 330 US ton |
| Bed area | 84.65” x 39.37” |
| Stroke length | 7.9" |
| Die height | 21.65" |
| Slide adjustment (powered) | 3.94" |
| Strokes per minute | 40-100 |
Additional Features
Wet clutch & brake, interlocked
Adjustable hydraulic overload protection
8-point bronze precision slide guiding system
Wide-spaced connections
Minimal bed deflection
Monitored lubrication flow
Micro-inch speed for easy die setting
Flywheel brake
Link motion with dynamic slide balancer
T-slots in bolster and slide to JIC standards
Die Protection
Light Curtains – Front and Rear
Presscam 8 Press Control
